Goldtool Linemans Test Set For RJ11 Blue
R1,079.00
Goldtool Lineman’s Test Set for RJ11 and ABN cords offers three test modes: Talk, Ring, and Monitor. It supports switchable tone or pulse dialing and provides protection against overvoltage. Designed in blue, it comes in retail packaging and includes a 3-month warranty.
| Weight | 1.1 lbs |
|---|---|
| Dimensions | 29.9 × 16.9 × 33.9 in |
Product Overview
This Goldtool Lineman’s Test Set For RJ11 is a new design to provide both DTMF and dial pulse output. The Lineman’s Test Set features line-powered operation, so no extended power is required unless operating on low voltage or dry circuits. It is used by installers, repair technicians and other authorized personnel for line testing and temporary communications. The polarity LED provides immediate visual indication for Tip (+) and Ring (–) polarity.
Highlights
• Three test modes Talk / Ring / Monitor
• Switchable tone or pulse dialling
• High impedance monitor will not interrupt data, conversation or signalling
• LED indicator for reversed polarity
• Memory for 10 numbers to be stored
• Last number redial 31 digits maximum
• Protection against over voltage
• Transients ringer signals
• Direct connection to most batteries and power supplies
• Volume control 3-postition control for up to 12dB of gain
• Spring loaded belt clip for easy carrying
• Durable cloth covered cord equipped with securely anchored strain relief, modular RJ11X plug, and two five way test clips
• Water-resistant; extra protection against severe weather conditions
• Space connector cord included
•Talk/Ring/Monitor three kind of tests function, its switch located on inside of handgrip.
• Switchable tone or pulse dialling. TONE/PULSE switch are located on inside of handgrip.
• The Hi impedance monitor will not disturb data, conversation, or signalling.
• LED indicates reversed polarity.
• Last number redial(31 digits maximum).
• Protection against excessive voltage, transients ringer signals, and direct connection to most batteries and power supplies.
Specifications
Stock Code TCT1900B
Description Goldtool Lineman Test Set Blue Colour
Loop Limit
• 5kΩ max at 48VDC
• (5k meter – 26Ga non loaded) nominal 15mA
• minimum loop current
DC Resistance
• 150Ω Typical at 80mA current
Monitor Impedance
• Low impedance(Ring mode)600Ω typical at 1kHz
High impedance (Monitor mode)
• 100kΩ typical at 1kHz
Rotary Dial Output -Pulsing Rate
• 10 ± 0.5 pulses a second
• Percent Break- 60% ± 2%
Interdigital Pause
• 8.5ms Typical
Leakage During Break
• >50kΩ
DTMF Output
• Tone Frequency Error – ± 1.5%
• Level Of Tone Pair- +2dBm max / -8dBm min
• Low vs. High Tone Difference–4dBm max
Dimensions and Weight
Dimensions (LxWxH) 22.4×7.12×7.0 cm
Weight 380g
About Goldtool Linemans Test Set RJ11 Blue
Goldtool Linemans Test Set For RJ11 Blue is a quality Networking-Passive that delivers dependable performance and real everyday value. Whether you are buying it for yourself or as a thoughtful choice for someone else, it combines practicality, solid build quality and convenience. This item is designed to fit into your routine easily while giving you a dependable product you can rely on over time.
What Makes This Product a Good Choice
There are many reasons shoppers pick this from our store. It offers a strong balance of quality and price, it is easy to use, and it ships with the secure checkout you expect from Scroll Specials. Every unit passes our quality check, and the support team is ready to help if you have a question. We focus on making your experience simple and enjoyable from the moment you order.
Shoppers trust us because we keep things honest: clear product details, fair pricing and support that actually responds. That peace of mind matters whether you are a first time buyer or a returning customer.
Key Benefits
- Quality materials and careful construction for long lasting use.
- Practical design that is simple to set up, use and keep clean.
- Great everyday value for your money.
- Backed by our quality check and responsive support.
- Suitable for a wide range of needs and everyday routines.
How to Use and Care for It
To get the best from this item, unpack it carefully, read the included guidance, and set it up in a clean and suitable spot. With Goldtool Linemans Test Set RJ11 Blue in particular, a little regular care goes a long way. Simple maintenance keeps it in great shape for longer, and following the provided guidance keeps everything working safely and properly.
Most products perform best when used as intended and kept in a reasonable environment. A few small habits, like cleaning it gently and storing it correctly, make a real difference to how long it lasts.
What to Check Before You Order
Before you purchase, take a moment to review the product details, dimensions or specifications, and the delivery options for your area. You can also browse more options in our online shop to compare similar items and find the best match for your needs.
If you are still deciding, reading the key features and comparing a few alternatives is the best way to be confident in your choice. Most customers do a little research before finalising their order and find it well worth the time, especially when they want a product that fits both their budget and their routine.
We also recommend checking the available colour, size or configuration options, because these details can change the final experience. Taking a few extra minutes now saves you from surprises later, and it helps ensure the product you receive is the one you actually want.
Shipping and Delivery
We aim to keep delivery simple and dependable. Once you place an order, it is carefully packed and handed over for delivery to your address. Most orders are dispatched quickly, and you can follow your package once it is on its way. Delivery windows can vary by area, so the estimate shown at checkout is the one to rely on.
If anything arrives less than perfect, our support team is here to help you sort it out quickly. Return options are available and clearly explained at checkout, so you always know what to expect.
Frequently Asked Questions
Is this easy to use? Yes, it is designed to be straightforward and suitable for everyday use. The setup is simple and clearly explained.
How long does delivery take? Delivery time depends on your location, and you can track it after you place your order.
Can I get support if I have an issue? Of course. Our team is happy to help with any questions you have, before or after you buy.
Is my payment secure? Yes. We use secure checkout so your payment details stay safe and protected.
Order Goldtool Linemans Test Set RJ11 Blue today at Scroll Specials and enjoy secure checkout, dependable service and quality you can count on. Your product is ready to be delivered.
